Test the Effect of One-Level Centrifugal Pump Arrangement in Series on Vibration Characteristics

Introduction

The centrifugal pump is a widely used device in various industries, including water treatment, oil and gas, and chemical processing. Its ability to efficiently transfer fluids from one location to another makes it an essential component in many systems. However, the operation of centrifugal pumps can be affected by various factors, including vibration. Vibration can cause damage to mechanical components, reduce pump efficiency, and potentially lead to system failure. Therefore, understanding the vibration characteristics of centrifugal pumps is crucial in designing and operating these systems effectively.

Background

Centrifugal pumps operate by using a rotating impeller to increase the pressure and flow rate of a fluid. The pump's performance is influenced by various factors, including the pump's design, operational conditions, and system configuration. In this study, we focus on the effect of a one-level centrifugal pump arrangement in series on vibration characteristics. The centrifugal pump used in this study has a maximum head of 17 m, a maximum capacity of 3.2 liters/second, and 1850 watt power. The system consists of PVC pipes as suction and disposal pipes, with a diameter of 2.5 inches and 3 inches, respectively.

Methodology

The testing of vibration characteristics starts from a force of 2 kg, increasing up to 2.8 kg, and vibration response is measured using a digital Hand Held Vibration Meter 908 vibration measuring device B. Measurement points are carried out in eight locations: at the bottom of the p-01 pump, p-02, P-03, P-04; at the P-05 pump, P-06; and in electromotor P-07, P-08. Measurements are made from axial, vertical, and horizontal directions.

Results

The results show that an increase in load and pump head causes an increase in the resulting vibrations. The highest displacement occurs at the first pump at point P-05 with a displacement value of 3.99 μm, while the lowest displacement occurs in the second electromotor at point P-08 with a value of 5.65 μm. In addition, the highest speed is recorded at the base of the pump at point P-03 with an acceleration value of 6.52 m/s, and the lowest acceleration is found in the pump at point P-06 with a horizontal acceleration of 5.30 m/s².

Analysis

In the centrifugal pump system, vibration is a common phenomenon and can affect the performance and life of the device. Increased load and head that cause excessive vibrations can be caused by several factors, including imbalances in the rotor, imperfect shaft, and not ideal operational conditions. It is essential to pay attention to the characteristics of this vibration, as excessive vibrations can cause damage to mechanical components, reduce pump efficiency, and potentially lead to system failure.

The measurement results show patterns that can be used to increase pump design and optimize operational performance. The selection of strategic measurement points in various pumps and electromotor locations provides valuable insight into how each component contributes to the overall vibrational characteristics.

Conclusion

This study focuses on the results of the load testing given to the centrifugal pump of one level that operates in series. The results show that an increase in load and pump head causes an increase in the resulting vibrations. The measurement results provide valuable insight into how each component contributes to the overall vibrational characteristics. It is recommended to conduct further analysis by considering various other factors such as the natural frequency of the system and resonance, in order to get a more comprehensive understanding of the dynamics of centrifugal pumps in various operational conditions.

Future Research Directions

In the future, further research is expected to explore vibration mitigation methods, such as the use of vibration dampers or adjustments to the inlet and pipe outlet angle, to improve the overall performance of the pump system. Additionally, the study of the effect of different pump designs and operational conditions on vibration characteristics is also essential in understanding the dynamics of centrifugal pumps.

Recommendations

Based on the results of this study, it is recommended to:

  • Conduct further analysis by considering various other factors such as the natural frequency of the system and resonance.
  • Explore vibration mitigation methods, such as the use of vibration dampers or adjustments to the inlet and pipe outlet angle.
  • Study the effect of different pump designs and operational conditions on vibration characteristics.

Limitations

This study has several limitations, including:

  • The use of a single centrifugal pump arrangement in series.
  • The limited number of measurement points.
  • The lack of consideration of other factors that may affect vibration characteristics.

Future Studies

Future studies should aim to:

  • Investigate the effect of different pump designs and operational conditions on vibration characteristics.
  • Explore vibration mitigation methods, such as the use of vibration dampers or adjustments to the inlet and pipe outlet angle.
  • Conduct further analysis by considering various other factors such as the natural frequency of the system and resonance.

Conclusion

In conclusion, this study focuses on the results of the load testing given to the centrifugal pump of one level that operates in series. The results show that an increase in load and pump head causes an increase in the resulting vibrations. The measurement results provide valuable insight into how each component contributes to the overall vibrational characteristics. It is recommended to conduct further analysis by considering various other factors such as the natural frequency of the system and resonance, in order to get a more comprehensive understanding of the dynamics of centrifugal pumps in various operational conditions.
