PropertySetDefinitionSets Are Not Imported Correctly

by ADMIN 53 views

Error Description and Steps to Reproduce

When an IFCRELDEFINESBYPROPERTIES has an IFCPROPERTYSETDEFINITIONSET, the RelatingPropertyDefinition holds a blank class, instead of a set of entities as would be expected.

Steps to Reproduce

  1. Add the following snippet to XmlSerializer.cpp here. This snippet is designed to add all the property sets inside a PropertySetDefinitionSet, if one exists, for an IfcRelDefinesByProperties entity.
#ifdef SCHEMA_HAS_IfcPropertySetDefinitionSet
    auto defines = object->file_->getInverse(object->id(), &(IfcSchema::IfcRelDefinesByProperties::Class()), -1);
    for(auto& o : *defines)
    {
        auto define = o->as<IfcSchema::IfcRelDefinesByProperties>();
        auto select = define->RelatingPropertyDefinition();
        if (select->as<IfcSchema::IfcPropertySetDefinitionSet>())
        {
            auto sets = select->as<IfcSchema::IfcPropertySetDefinitionSet>()->operator boost::shared_ptr<aggregate_of<IfcSchema::IfcPropertySetDefinition>>();
            for (auto pset : *sets)
            {
                format_entity_instance(mapping, pset, child, true);
            }
        }
    }
#endif
  1. Run IfcConvert to convert the following file to XML

ColumnPSetsOfSets.ifc.txt

  1. The conversion will fail with the error
[Error] [2025-03-12 16:42:29] Type held at index 0 is class Blank and not class boost::shared_ptr<class aggregate_of_instance>

Debug information

The parsing works up till here. The construct_ method correctly gathers the references and passes them to the lambda as a std::vector<reference_or_simple_type>:

https://github.com/IfcOpenShell/IfcOpenShell/blob/7e9985758fc88293afcc6d5d23b1ecc06ce7a6c8/src/ifcparse/IfcFile.cpp#L306-L318

However, because name is -1, this snippet never does anything with them, and so the IfcEntityInstanceData is given the default storage_t.

name is -1 because this is called from,

https://github.com/IfcOpenShell/IfcOpenShell/blob/7e9985758fc88293afcc6d5d23b1ecc06ce7a6c8/src/ifcparse/IfcParse.cpp#L724

Understanding the Issue

The issue arises from the fact that IfcRelDefinesByProperties expects a single reference to a IfcPropertySetDefinitionSelect, not a set. However, IfcPropertySetDefinitionSet is a set of entities, which cannot be directly referenced by IfcRelDefinesByProperties.

Proposed Solution

One possible solution is to create an anonymous object for the set, which would allow IfcRelDefinesByProperties to reference it correctly. However, this would require significant changes to the IFC schema and the parsing code.

Alternative Solution

Another possible solution is to modify the load function to pass entity_instance_name instead of -1, which would allow the references in the set to be resolved correctly. However, this would require changes to the parsing code and may have unintended consequences.

Conclusion

The issue of PropertySetDefinitionSets not being imported correctly is a complex one, requiring significant changes to the IFC schema and the parsing code. While there are possible solutions, they are not without their challenges and may have unintended consequences. Further investigation and testing are required to determine the best course of action.

Code Changes

To fix the issue, the following code changes are required:

  • Modify the XmlSerializer.cpp file to add the snippet that adds all the property sets inside a PropertySetDefinitionSet, if one exists, for an IfcRelDefinesByProperties entity.
  • Modify the IfcParse.cpp file to pass entity_instance_name instead of -1 to the load function.
  • Modify the IfcFile.cpp file to correctly resolve the references in the set.

Testing

To test the changes, the following steps should be taken:

  • Run IfcConvert to convert the ColumnPSetsOfSets.ifc file to XML.
  • Verify that the conversion is successful and the RelatingPropertyDefinition holds a set of entities instead of a blank class.

Future Work

Further investigation and testing are required to determine the best course of action for fixing the issue of PropertySetDefinitionSets not being imported correctly. This may involve modifying the IFC schema and the parsing code, as well as testing the changes to ensure that they do not have unintended consequences.

Q: What is the issue with PropertySetDefinitionSets not being imported correctly?

A: The issue arises from the fact that IfcRelDefinesByProperties expects a single reference to a IfcPropertySetDefinitionSelect, not a set. However, IfcPropertySetDefinitionSet is a set of entities, which cannot be directly referenced by IfcRelDefinesByProperties.

Q: What is the proposed solution to fix the issue?

A: One possible solution is to create an anonymous object for the set, which would allow IfcRelDefinesByProperties to reference it correctly. However, this would require significant changes to the IFC schema and the parsing code.

Q: What is the alternative solution to fix the issue?

A: Another possible solution is to modify the load function to pass entity_instance_name instead of -1, which would allow the references in the set to be resolved correctly. However, this would require changes to the parsing code and may have unintended consequences.

Q: What code changes are required to fix the issue?

A: To fix the issue, the following code changes are required:

  • Modify the XmlSerializer.cpp file to add the snippet that adds all the property sets inside a PropertySetDefinitionSet, if one exists, for an IfcRelDefinesByProperties entity.
  • Modify the IfcParse.cpp file to pass entity_instance_name instead of -1 to the load function.
  • Modify the IfcFile.cpp file to correctly resolve the references in the set.

Q: How can I test the changes to ensure that they fix the issue?

A: To test the changes, the following steps should be taken:

  • Run IfcConvert to convert the ColumnPSetsOfSets.ifc file to XML.
  • Verify that the conversion is successful and the RelatingPropertyDefinition holds a set of entities instead of a blank class.

Q: What are the potential consequences of modifying the IFC schema and the parsing code?

A: Modifying the IFC schema and the parsing code can have unintended consequences, such as breaking existing functionality or introducing new bugs. Therefore, it is essential to thoroughly test the changes before releasing them.

Q: Can I create an anonymous object for the set to fix the issue?

A: Yes, creating an anonymous object for the set is one possible solution to fix the issue. However, this would require significant changes to the IFC schema and the parsing code.

Q: What is the current status of the issue?

A: The issue is currently being investigated and tested. Further investigation and testing are required to determine the best course of action for fixing the issue.

Q: Who can I contact for further information or assistance?

A: You can contact the IfcOpenShell development team for further information or assistance. They can provide guidance on the best course of action for fixing the issue and answer any questions you may have.

Q: What are the next steps for fixing the issue?

A: The next steps for fixing the issue are to:

  • Continue investigating and testing the issue.
  • Determine the best course of action for fixing the issue.
  • Implement the changes required to fix the issue.
  • Thoroughly test the changes to ensure that they fix the issue and do not introduce new bugs.
