Introduction

A biapoiada beam is a type of beam that is supported at both ends and subjected to various types of loads, including distributed loads, point loads, and moments. In this article, we will analyze a biapoiada beam and calculate the value of the moment (m) and shear force (v) at a given point, knowing that the distance between the supports is 8m and the distributed load is 175 kN.

Theoretical Background

To analyze a biapoiada beam, we need to use the principles of statics and the equations of equilibrium. The moment (m) and shear force (v) at a given point can be calculated using the following equations:

  • Moment (m): m = ∫(w(x) * x) dx
  • Shear force (v): v = ∫(w(x)) dx

where w(x) is the distributed load as a function of x, and x is the distance from the left support.

Given Data

  • Distance between supports: 8m
  • Distributed load: 175 kN

Calculating the Moment (m)

To calculate the moment (m), we need to integrate the distributed load (w(x)) with respect to x. Since the distributed load is constant, we can write:

w(x) = 175 kN/m

The moment (m) can be calculated as:

m = ∫(175 kN/m * x) dx = 175 kN/m * (x^2 / 2) = 87.5 kN/m * x^2

Calculating the Shear Force (v)

To calculate the shear force (v), we need to integrate the distributed load (w(x)) with respect to x. Since the distributed load is constant, we can write:

v = ∫(175 kN/m) dx = 175 kN/m * x

Calculating the Values of m and v

To calculate the values of m and v at a given point, we need to substitute the value of x into the equations for m and v.

Let's assume we want to calculate the values of m and v at x = 4m (which is the midpoint of the beam).

m = 87.5 kN/m * (4m)^2 = 87.5 kN/m * 16m^2 = 1400 kNm

v = 175 kN/m * 4m = 700 kN

Conclusion

In this article, we analyzed a biapoiada beam and calculated the value of the moment (m) and shear force (v) at a given point, knowing that the distance between the supports is 8m and the distributed load is 175 kN. We used the principles of statics and the equations of equilibrium to derive the equations for m and v, and then substituted the value of x into these equations to calculate the values of m and v.

References

  • [1] Timoshenko, S. P. (1955). Strength of Materials. New York: McGraw-Hill.
  • [2] Gere, J. M. (2003). Mechanics of Materials. Stamford, CT: Cengage Learning.

Glossary

  • Biapoiada beam: A type of beam that is supported at both ends and subjected to various types of loads.
  • Moment (m): A measure of the rotational force acting on a beam.
  • Shear force (v): A measure of the force acting on a beam in the direction perpendicular to the axis of the beam.
  • Distributed load: A load that is applied over a certain area of the beam.
  • Point load: A load that is applied at a single point on the beam.
  • Equations of equilibrium: A set of equations that describe the balance of forces and moments acting on a beam.
